Description
Basic functions and uses
Function : As a motion controller, it is used to control and drive various types of servo motors.
Application : Suitable for various industrial and application scenarios requiring precise control of motor motion.
Key parameters and performance
control mode : Support electronic gear, position, speed, torque control mode.
External control command : Support step pulse, ±10V analog speed/torque, PWM speed/torque.
I/O : 1 ±10V analog input, 6 digital input, 2 digital programmable output.
feedback : Support orthogonal incremental encoder, digital hall, back electromotive force feedback.
protection : with over current, over voltage, under voltage, short circuit, ground, over temperature and other multiple protection.
Physical specifications and dimensions
Dimensions : 168 x 100 x 31mm.
Other features
power supply voltage : single DC power supply, voltage range 18-160VDC.
current : maximum continuous current 12A, maximum peak current 36A.
communication : The PC software adjusts parameters through RS232 communication Settings.
