CS513

¥2,034.00

4. Features



  • High – Precision Level Measurement: It is equipped with advanced sensing technology that can measure the liquid level with high accuracy. The measurement accuracy can reach up to ±0.1% of the full – scale range, providing reliable data for control and monitoring purposes.
  • Non – Contact Measurement: The CS513 uses non – contact measurement methods, such as ultrasonic or radar technology. This eliminates the need for direct contact with the liquid, which is beneficial for measuring corrosive, viscous, or dirty liquids.
  • Multiple Output Options: It offers multiple output options, including analog outputs (4 – 20mA, 0 – 10V) and digital outputs (RS – 485, Modbus). This allows for easy integration with different control systems and data acquisition devices.

5. Stability and Reliability



  • Robust Construction: The CS513 is built with a durable housing that provides protection against dust, moisture, and mechanical vibrations. This makes it suitable for use in harsh industrial and environmental conditions.
  • Long – Term Stability: It has excellent long – term stability, with minimal drift over time. This ensures that the measurement results remain accurate and reliable over an extended period, reducing the need for frequent calibration.
  • Fault – Tolerant Design: The device has a fault – tolerant design that can detect and handle common faults, such as sensor malfunctions or communication errors. In case of a fault, it can provide an alarm signal and take appropriate actions to prevent incorrect data from being used.
Category:

Description

3. Weight and Dimensions



  • Weight: The CS513 weighs approximately 0.6 kg. Its lightweight design makes it easy to install and handle, especially when mounting it on tanks or other structures.
  • Dimensions: It has dimensions of about 100 mm in length, 60 mm in width, and 30 mm in height. These compact dimensions allow it to be installed in tight spaces without taking up much room.

4. Features



  • High – Precision Level Measurement: It is equipped with advanced sensing technology that can measure the liquid level with high accuracy. The measurement accuracy can reach up to ±0.1% of the full – scale range, providing reliable data for control and monitoring purposes.
  • Non – Contact Measurement: The CS513 uses non – contact measurement methods, such as ultrasonic or radar technology. This eliminates the need for direct contact with the liquid, which is beneficial for measuring corrosive, viscous, or dirty liquids.
  • Multiple Output Options: It offers multiple output options, including analog outputs (4 – 20mA, 0 – 10V) and digital outputs (RS – 485, Modbus). This allows for easy integration with different control systems and data acquisition devices.

5. Stability and Reliability



  • Robust Construction: The CS513 is built with a durable housing that provides protection against dust, moisture, and mechanical vibrations. This makes it suitable for use in harsh industrial and environmental conditions.
  • Long – Term Stability: It has excellent long – term stability, with minimal drift over time. This ensures that the measurement results remain accurate and reliable over an extended period, reducing the need for frequent calibration.
  • Fault – Tolerant Design: The device has a fault – tolerant design that can detect and handle common faults, such as sensor malfunctions or communication errors. In case of a fault, it can provide an alarm signal and take appropriate actions to prevent incorrect data from being used.

1. Real – world Case



In a large – scale water treatment facility, the CS513 was utilized to monitor the water level in a large reservoir. The reservoir is a crucial part of the water treatment process, as it stores the raw water before treatment. One day, heavy rainfall occurred in the area, causing the water level in the reservoir to rise rapidly.



The CS513, which was installed at the side of the reservoir, continuously measured the water level with high precision. When the water level approached the maximum safe level, the CS513 sent an alarm signal to the control center. The operators in the control center were then able to open the spillway gates in time to release the excess water, preventing the reservoir from overflowing and potential damage to the surrounding areas. Thanks to the reliable performance of the CS513, the water treatment facility was able to maintain normal operation and ensure the safety of the local water supply.

2. Applications



  • Water and Wastewater Management: In addition to reservoir level monitoring, it can be used in water tanks, sewage treatment plants, and irrigation systems. It helps to control the filling and emptying processes, ensuring proper water management.
  • Industrial Process Control: In industries such as chemical manufacturing and food processing, the CS513 can be used to monitor the level of liquids in storage tanks, reactors, and other vessels. This ensures the correct amount of raw materials and products are maintained in the production process.
  • Environmental Monitoring: For environmental applications, it can be used to monitor the water level in rivers, lakes, and wetlands. This data is useful for flood prediction, water resource management, and ecological research.

6. Parameter Specifications



  • Power Supply: It operates on a 12 – 24V DC power supply, with an allowable voltage range of 10.8V to 26.4V. This wide voltage range ensures stable operation even in the presence of power fluctuations.
  • Measurement Range: The measurement range can vary depending on the model, but it typically covers from 0.2 to 10 meters.
  • Temperature Range: It can operate in a temperature range of – 20°C to 60°C, which is suitable for most industrial and environmental applications.
  • Response Time: The response time is typically less than 1 second, allowing for real – time monitoring of the liquid level.
