1. Product Description
Yokogawa CIMR-HB4A0018ABC is a significant component in Yokogawa’s range of automation products. It plays a crucial role in various industrial automation applications, providing efficient control and power management for electrical systems.
The CIMR-HB4A0018ABC is primarily used as an inverter in industrial settings. Its core function is to convert the fixed frequency and voltage of the input power supply into a variable frequency and voltage output, which can be precisely adjusted to control the speed and torque of electric motors. This enables seamless control of motor-driven equipment, such as pumps, fans, and conveyor belts. For example, in a manufacturing plant that produces consumer goods, the CIMR-HB4A0018ABC can be used to control the speed of the conveyor belts that transport products along the production line. By adjusting the output frequency and voltage of the inverter, operators can increase or decrease the speed of the conveyor belts according to the production requirements. In a water treatment plant, this inverter can be employed to control the speed of pumps, ensuring the efficient operation of the water treatment process.
The CIMR-HB4A0018ABC offers several notable advantages. It has high reliability, which allows it to operate stably even in harsh industrial environments with electrical interference, temperature variations, and mechanical vibrations. Its advanced control algorithms provide precise motor control, reducing energy consumption and improving the overall efficiency of the system. Additionally, it features a user-friendly interface, making it easy for operators to configure and monitor the inverter’s operation.
2. Product Parameters
| Parameter | Details |
|---|---|
| Rated Input Voltage | 380V – 480V AC, 3-phase (±10%) |
| Rated Output Voltage | 0V – Rated Input Voltage (Variable) |
| Rated Input Current | Approximately 40A |
| Rated Output Current | 38A |
| Rated Power | 18.5kW |
| Frequency Range | 0Hz – 400Hz |
| Control Method | Vector Control, V/F Control |
| Communication Interfaces | RS-485, Ethernet (Optional) |
| Compatibility | Compatible with a wide range of standard electric motors |
| Operating Temperature Range | -10°C to 50°C (with derating above 40°C) |
| Humidity Range | 5% – 95% (non-condensing) |
| Protection Level | IP20 |
3. Advantages and Features
- High Reliability: In a cement manufacturing plant, where there is a lot of dust, vibration, and electrical noise, the CIMR-HB4A0018ABC has an average mean time between failures (MTBF) of over 200,000 hours. Over several years of operation in the plant’s motor control system, it has maintained stable performance, ensuring the continuous operation of critical equipment such as conveyor belts and fans. This has significantly reduced the occurrence of system failures caused by inverter malfunctions compared to some less reliable models.
- Energy Efficiency: In a large commercial building’s HVAC system, the CIMR-HB4A0018ABC was installed to control the speed of the air handling unit fans. By using the inverter’s advanced control algorithms, the speed of the fans could be adjusted according to the actual cooling or heating requirements. This resulted in an energy savings of approximately 30% compared to a fixed-speed system, reducing the building’s energy consumption and operating costs.
- User-Friendly Interface: In a food processing plant, operators found it easy to configure and monitor the CIMR-HB4A0018ABC due to its intuitive interface. They could quickly adjust the motor speed, set up protection functions, and view real-time operating data, which improved the efficiency of the production process and reduced the risk of operator errors.
4. Application Areas and Application Cases
The CIMR-HB4A0018ABC is applicable to a wide range of industries and scenarios, including manufacturing (such as automotive, electronics, food processing), energy (such as power generation, oil and gas), building automation (such as HVAC systems in commercial buildings), and water treatment.
In a large oil refinery, the CIMR-HB4A0018ABC was used to control the speed of the pumps that transport crude oil and refined products. By precisely controlling the pump speed, the refinery was able to optimize the flow rate of the fluids, reducing energy consumption and improving the efficiency of the refining process. The inverter’s high reliability also ensured the continuous operation of the pumps, minimizing downtime and increasing the overall productivity of the refinery.
5. Comparison with Competitors
When compared to similar products in the market, the CIMR-HB4A0018ABC has several distinct advantages. In terms of reliability, its longer MTBF and better ability to withstand harsh environments give it an edge over many other inverters. Its advanced control algorithms provide more precise motor control, resulting in higher energy efficiency compared to some competing products. Additionally, the user-friendly interface of the CIMR-HB4A0018ABC makes it more accessible to operators, reducing the need for extensive training and minimizing the risk of errors, which is an advantage over products with more complex interfaces.
6. Selection Suggestions
- Compatibility: When choosing the CIMR-HB4A0018ABC, it is essential to ensure its compatibility with the electric motors you plan to use. Check the motor’s rated power, voltage, and current requirements to ensure they match the inverter’s specifications. Also, consider the control method required for your application and make sure the inverter supports it.
- Installation Environment: Take into account the installation environment of the inverter. The CIMR-HB4A0018ABC has a specific operating temperature and humidity range. If the installation environment exceeds these limits, appropriate measures such as installing air conditioning or dehumidification equipment may be required. Additionally, consider the level of electrical interference in the environment and take appropriate shielding measures if necessary.
- Budget: Compare the price of the CIMR-HB4A0018ABC with similar products in the market. In addition to the initial purchase cost, consider the long-term operating costs, including energy consumption, maintenance costs, and potential repair expenses. While the CIMR-HB4A0018ABC offers high performance and reliability, it is important to balance the quality and cost according to your specific budget and requirements.
7. Precautions
- Installation: Before installing the CIMR-HB4A0018ABC, make sure to power off the entire electrical system and all related equipment. Follow the installation instructions carefully to correctly connect the power supply, motor, and control cables. Ensure that all connections are secure and there are no loose or damaged wires. When installing the inverter in a control cabinet, make sure there is enough space for ventilation to prevent overheating.
- Safety: Do not touch the internal components of the inverter when it is powered on. Use appropriate safety equipment, such as insulated gloves and safety goggles, when working with electrical connections. In case of any abnormalities or malfunctions during the operation of the inverter, immediately power off the system and contact professional technicians with experience in Yokogawa equipment for inspection and repair.
- Maintenance: Regularly inspect the inverter for signs of dust, moisture, or mechanical damage. Periodically check the electrical connections for proper tightening and the cooling fans for proper operation. If software updates are available, follow the manufacturer’s instructions to update the inverter’s firmware, but remember to backup important configuration data before the update to prevent data loss. Also, conduct regular performance tests on the inverter to ensure its optimal operation.
Shanxi Runsheng Import and Export Co., Ltd. is your reliable partner. We provide sales and technical support for CIMR-HB4A0018ABC and other automation spare parts. Please visit our website www.sxrsrobot.com or contact us, and we will serve you wholeheartedly
