CI522A 3BSE018283R1

Description

specification
Manufacturer: ABB.
Product Number: 3BSE018283R1.
Product model: CI522A.

dav

trait
High precision measurement: The ability to measure various analog signals with high precision and convert them into digital formats to provide accurate input data for the control system.
Fast response: It has a fast response time and can process and transmit analog signals in real time to ensure the real-time and stability of the system.
Multiple input signal types: Support a variety of different input signal types, such as 0-10V, 4-20mA, etc., convenient for users to connect various sensors.
Scalability: Modular design, easy for users to configure and expand. By combining with other modules, a complete automatic control system can be built.
Easy to program and maintain: Supports parameter setting and function configuration through programming, which is convenient for users to customize according to actual needs. At the same time, it is also easy to maintain and upgrade, reducing maintenance costs.
Wide application: Due to its high precision, fast response and scalability, it is widely used in a variety of industrial automation and control systems requiring high precision measurement.

dav

Size and weight
Size:
For analog input modules, the AF100 interface module has an interface size of 26.5 cm x 2.7 cm x 12 cm with the S800 I/O.
For the power module version, the dimensions are 482.6 x 216.5 x 130 mm.
Weight:
The interface module of the analog input module weighs 0.2 kg and the shipping weight is 1.5 kg.
The power module version weighs 14.5 kg.

dav

argument
Type: High precision analog input module.
Application: Widely used in chemical, electric power, pharmaceutical and other industries control system.
Rated power: 2200 watts for the power module version.
Input voltage: 200-240 volts AC for the power module version.
Output voltage: For the power module version, it is 24 volts DC.
Efficiency: >90% (for power module version).
