CC-PAIH01

Description

trait
High precision and resolution: provides accurate analog input signal measurement and conversion
High-speed data acquisition: Maximum update rate of 10ms for applications requiring high-speed data acquisition and processing
Flexibility and versatility: Supports a wide range of industrial applications, including automation, manufacturing and process control
Easy installation and maintenance: Unique patented hot channel shape, components can be implemented in a redundant manner, easy installation and maintenance
Strong anti-interference ability: can effectively resist external electromagnetic interference and noise, to ensure the accuracy and reliability of the signal

effect
Analog signal input: Receive external analog signals, such as temperature, pressure, flow, etc., and convert them into digital signals for monitoring, control, and data processing
Data acquisition and recording: The numerical value of the analog input signal is collected and recorded in real time and sent to the control system or data processing unit
Industrial Automation control: As an important part of the industrial automation system, CC-PAIH01 module can improve production efficiency and ensure the stability and reliability of the production process

argument
Number of channels: Typically has 8 differential inputs
Voltage range: +/-10V
Resolution: 16 bits
Maximum update rate: 10ms
Power Supply: +5V DC, Max 100 mA
Backplane current load: 650 mA@5V DC
Operating temperature: 0°C to 60°C (32°F to 140°F)
Storage temperature: -40°C to 85°C (-40°F to 185°F)
Humidity range: 5-95%RH, non-condensing
