Description
Specifications and types :
Type : video camera.
technology : 3CCD.
CCD type : Type 1/4.7 IT Advanced HAD CCD (or Super HADTM CCD).
Weight and dimensions :
Weight : 2.7kg.
Dimensions : 180mm×205mm×211mm.
Function and application :
Suitable for auditorium, distance teaching, corporate training, high-end video conferencing, event shooting and limited TV broadcasting and other remote control shooting applications.
parameter :
Total number of pixels : 1,070,000.
resolution : 960×720 in 4:3 mode 1152×648 in 16:9 mode.
zoom : 12x optical zoom, 48x digital zoom.
Focal length range : f-3.6 to f2.8 (or f-3.6 to 43.2mm).
Minimum illumination : 7lx at F1.6.
SNR : 50Db.
Shutter speed : 1/10000 to 1/4 second in NTSC mode, 1/10000 to 1/3 second in PAL mode.
Other features :
Supports automatic and manual gain adjustment, a variety of white balance Settings, and can switch 6 analog output interfaces.
Equipped with backlight compensation function, operating temperature range from 0 to 40 degrees.
The power requirement is DC12V, and the power consumption is 21.6W (excluding the optional card).
