Bently Nevada 3500/72M Parameters, Specifications, Dimensions, Weight, Series, Features, and Functions
Parameters:
The Bently Nevada 3500/72M is a monitoring module designed for industrial applications.
It typically operates within a voltage range of 24V.
The module can handle a current range of 100-400A.
Specifications:
The 3500/72M incorporates reliable microprocessor technology for its design and application.
It accepts input from 1 to 4 probe signals.
The module features adjustable alarm settings and thresholds.
Dimensions and Weight:
The exact dimensions (length, width, height) of the 3500/72M are not provided in the given resources.
The weight of the module is approximately 1.5kg or 2KG depending on the source.
Series:
The Bently Nevada 3500/72M belongs to the Bently Nevada 3500 series of industrial monitoring and control products.
Features:
Multipurpose Monitoring: The 3500/72M is a four-channel monitor that accepts input from proximity sensors, conditions the signals, and provides both dynamic and static position measurements.
Programmable Alarms: Users can program the module to compare the conditioned signals with programmable alarm settings.
Flexibility: Each channel of the 3500/72M can be programmed to perform functions such as rod position measurement, drop rod measurement, and super compressor measurement.
Functions/Role:
Position Monitoring: The 3500/72M is primarily used for position monitoring in reciprocating compressors, providing mechanical protection by continuously comparing monitoring parameters with configured alarm thresholds.
Alarm Generation: If any monitored parameter exceeds its configured threshold, the module generates alarms, notifying operators of potential issues or failures.
Integration with Industrial Systems: As part of the 3500 series, the 3500/72M seamlessly integrates with other components of industrial automation and control systems.
