Description
Main role :
temperature monitoring : used to monitor various temperature parameters, such as radial bearing, thrust bearing metal temperature, compressor suction and exhaust temperature, etc.
Key parameters :
Input signal : Processes signals from the resistance temperature detector (RTD) and thermocouple (TC).
Number of channels : six temperature monitoring channels.
Output function : no recorder output (different from 3500/61).
Specifications and dimensions :
External terminal : non-isolated version, bulkhead rack accuracy ±3°C(25°C).
Operating temperature : -30°C to +65°C.
Storage temperature : -40°C to +85°C.
Physical dimensions : 241.3mm x 24.4mm x 241.8mm (H x W x D).
Weight : 0.91 kg (2.0 lb).
Other features :
conditional trigger : Conditional trigger can be set to trigger an alarm when the temperature exceeds a preset range.
programmable Settings : The module can be flexibly configured through programming software, including channel configuration, alarm Settings, etc.
easy to use : equipped with easy to use programming interface, easy to develop and maintain.
stable and reliable : the use of high quality materials and manufacturing process to ensure stable operation in harsh environments.
