Description
1.Parameters:
–Input Signal Range: +10.0 V to -24.0 V, suitable for a wide range of sensor inputs.
–Input Impedance: 20 kΩ (standard), 40 kΩ (TMR), 7.15 kΩ (internal barrier), ensuring compatibility with various sensor types.
–Power Consumption: 5.8 watts, typical value.
2.Specifications:
–Channels: 2-channel module, capable of accepting input from two sensors simultaneously.
–Configuration Software: Uses the 3500 rack configuration software for easy setup and programming.
–Monitoring Capabilities: Monitors shaft speed, rotor acceleration, or rotor direction, and compares measurements against user-programmable alarm setpoints.
3.Dimensions & Weight:
–Dimensions: The exact dimensions may vary, but generally, BENTLY 3500 series modules are designed for 19-inch rack mounting.
–Weight: Approximately 2.5 kg,
5.Features:
–Versatile Input: Accepts input from proximity probes or magnetic sensors.
–Configurable Alarms: Offers multiple configuration options for speed monitoring, setpoint alarms, and notifications (e.g., zero-speed, rotor acceleration, reverse rotation).
–LED Indicators: Front panel LED indicators for OK, TX/RX, and Bypass status.
–High Reliability: Designed for reliable operation in harsh industrial environments.
6.Functions:
–Shaft Speed Monitoring: Monitors the rotational speed of machinery to ensure proper operation.
–Alarm Generation: Generates alarms when measured values exceed user-defined setpoints, helping to prevent potential equipment damage or downtime.
–Rotor Acceleration & Direction Monitoring: Monitors rotor acceleration and direction, providing valuable insights into machine health and performance.
–Integration: Integrates seamlessly with other BENTLY 3500 series modules to form a comprehensive mechanical monitoring system.
