Description
Bently 3500/25 Parameters, Specifications, Dimensions, Weight, Series, Features, and Functions (in English)
Parameters and Specifications:
Module Type: The Bently 3500/25 is an enhanced keyphasor signal module designed for industrial monitoring systems.
Input Compatibility: The module accepts input signals from either proximity probes or magnetic pickups.
Signal Conversion: It converts the input signals into digital keyphasor signals, indicating when the key phase mark on the shaft aligns with the keyphasor sensor.
Signal Range: The input signal range is from -0.8V to -21.0V for non-isolated I/O modules and +5V to -11V for isolated I/O modules.
Power Consumption: The typical power consumption is 3.2 watts.
Dimensions and Weight:
Dimensions: The module measures 3500mm in length and 25mm in width. The exact height and depth dimensions are not provided, but it is described as a half-height, dual-channel module.
Weight: The module weighs approximately 0.46 kilograms or 1.01 pounds.
Series:
The Bently 3500/25 belongs to the Bently Nevada 3500 series of industrial monitoring products.
Features:
Enhanced Keyphasor Signal Processing: Compared to previous designs, it offers improved keyphasor signal processing capabilities.
Dual-Channel: The module has two input channels, enabling it to receive and process signals from two sensors simultaneously.
Compatibility and Downward Compatibility: It is fully compatible with existing Keyphasor modules and can be used in traditional systems.
Multiple Configurations: It supports both normal and paired configurations, with a maximum of four or eight Keyphasor signals, respectively.
Isolation Option: An isolated I/O module version is available for applications that require isolation from other systems.
Functions/Role:
Signal Provider: The 3500/25 module serves as a signal provider to the monitoring modules in the 3500 rack, enabling them to detect and analyze the rotational position and speed of machinery.
Monitoring Capabilities: It can be used for various monitoring applications, including vibration and temperature monitoring, providing valuable data for maintenance and troubleshooting.
Data Acquisition and Analysis: The module collects and processes data, which can then be analyzed by engineers and operators to understand the operating status of the equipment and take necessary actions.
Please note that the specifications, dimensions, and features provided here are based on generally available information. For the most accurate and up-to-date information, it is recommended to consult the official documentation or contact the manufacturer directly.
