Bently 3500/22M Parameters, Specifications, Dimensions, Weight, Series, Features, and Functions
Parameters and Specifications:
Model: The Bently 3500/22M is a transient data interface module (TDI) designed for industrial monitoring systems.
Compatibility: It interfaces between the 3500 monitoring system and compatible software such as System 1 mechanical management software.
Measurement Range: The measurement range depends on the specific sensors connected to the module.
Accuracy: The module offers ±0.1% full-scale accuracy.
Signal Compatibility: It supports various input signals, including 4-20mA, 0-5V, 0-10V standard analog signals, as well as digital signals like Modbus and Profibus.
Power: The module operates on 100-240V AC power with a maximum power consumption of 25W.
Dimensions and Weight:
Dimensions: The module measures approximately 138mm x 138mm x 25mm (width x depth x height).
Weight: The weight of the module can vary, with some sources indicating 0.5kg and others specifying 1.2kg. It’s advisable to consult official documentation for the most accurate weight.
Series:
The 3500/22M belongs to the Bently Nevada 3500 series of industrial monitoring products.
Features:
High Performance: The module offers high precision, reliability, and stability for industrial monitoring applications.
Combined Functionality: The TDI combines the functionality of the 3500/20 rack interface module (RIM) and communication processors like TDXnet.
Dynamic Data Collection: It continuously collects steady-state and transient waveform data and transmits it to the host software through an Ethernet link.
TMR Capability: For three-module redundancy (TMR) applications, a TMR version of the TDI is available.
Functions/Role:
Data Interface: The 3500/22M TDI serves as the interface between the 3500 monitoring system and compatible software, facilitating data exchange and communication.
Data Collection and Transmission: It collects data from various sensors and monitoring devices connected to the 3500 rack and transmits it to the main computer software for analysis and monitoring.
System Integration: By integrating with the 3500 rack and other components, the TDI enables a comprehensive and seamless industrial monitoring solution.
Please note that the specifications, dimensions, and features provided here are based on generally available information. For the most accurate and up-to-date information, it is recommended to consult the official documentation or contact the manufacturer directly.
