Description
The Bently Nevada 3500/22M is a high-performance industrial monitoring system component, specifically a transient data interface module. Here are its parameters, specifications, dimensions, weight, series, features, and functions described in English:
Parameters and Specifications:
Input Signal Range: Typically accepts input signals ranging from -10 Vdc to +10 Vdc.
Power Consumption: With a power rating of 7.7 watts, it efficiently consumes power while operating.
Axis and Sensor Power: Both are rated at -24 Vdc, ensuring stable power supply to the module.
Dimensions and Weight:
Dimensions: The approximate dimensions are 9.50 x 4.50 x 1.00 inches (or 241.3 x 114.3 x 25.4 mm), allowing for a compact fit in industrial systems.
Weight: The module weighs approximately 0.85 pounds (or 0.385 kg), making it lightweight and easy to handle.
Series:
The 3500/22M belongs to the 3500 series of monitoring systems, which are renowned for their reliability and precision.
Features:
High Precision and Reliability: The module offers high precision and reliability, making it suitable for critical industrial monitoring applications.
Versatile Compatibility: It can interface with various sensors, accepting standard analog signals such as 4-20mA, 0-5V, and 0-10V, as well as digital signals (Modbus, Profibus, etc.).
Dynamic Data Capture: TDI (Transient Data Interface) has the ability to record dynamic, high-resolution transient data using an optional channel enabling disk.
Functions and Applications:
Monitoring and Control: The 3500/22M module is used for real-time monitoring and control of industrial processes, enabling operators to make informed decisions.
Fault Detection and Prevention: It helps in detecting and preventing faults in industrial equipment, thereby reducing downtime and maintenance costs.
Integration with 3500 System: As a transient data interface module, it serves as the link between the 3500 monitoring system and compatible software such as System 1 status monitoring and diagnostic software.
Please note that for the most accurate and up-to-date information on the specific parameters, specifications, dimensions, weight, and other technical details of the Bently Nevada 3500/22M module, it is recommended to consult the official Bently Nevada documentation or contact Bently Nevada directly. This will ensure that you have access to the latest and most accurate information regarding the module’s features, functions, and compatibility.
