Description
argument
Input signal: Support -10 Vdc to +10 Vdc signal input.
Shaft power supply: -24 Vdc.
Sensor power supply: -24 Vdc.
Power consumption: 7.7 Watts.
Communication protocol: Support BN main computer protocol and BN TDI protocol, and 3500 configuration software and 3500 data acquisition and display software communication.
Communication interface: RS232, Ethernet TCP/IP (including 10 Base-T/100 Base-TX and 100 Base-FX fiber interface).
specification
Operating temperature: -30℃ to +65℃ (-22 F to +150 F), storage temperature: -40℃ to +85℃ (-40 F to +185 F).
Humidity: 95%, non-condensing.
Battery life: Charged TDI can be used for 38 years at 50 ° C, uncharged TDI can be used for 12 years at 50 ° C.
Size and weight
Dimensions: 9.50 in x 0.96 in x 9.52 in (or 241.3mm x 24.4mm x 241.8mm).
Weight: 0.91kg (2.0lbs).
trait
Data acquisition capability: Support multi-event input per speed, maximum 20kHz; Supports data acquisition from RPM and time interval, including acceleration and deceleration phases.
Alarm data collection: data before and after the alarm can be collected, including 1-second data 10 minutes before the event and 1 minute after the event.
Waveform sampling: can collect 48 channels of waveform data, support DC coupled waveform data, user configurable synchronous waveform data sampling frequency.
Communication flexibility: Support a variety of communication protocols and interfaces, including RS232, Ethernet TCP/IP, etc.
Security and reliability: Equipped with perfect security functions, such as fault detection, security locking, encrypted communication, etc., to improve the security and reliability of the control system.
