Description
Parameters
- Power Supply Voltage: 24 VDC123
- Operating Temperature: -20°C to 60°C123
- Relative Humidity: 5% to 95% (non-condensing)1
- Input Signal: Voltage signal (e.g., -10 Vdc to +10 Vdc for 3500/22M)3
- Power Consumption: 25 W (for TDI module)1 or 7.7 W (for 3500/22M)3
- Sensor Power: -24 Vdc3
Specifications
- Product Type: Transient Data Interface (TDI) Module1356
- Series: 35001345
- Dimensions:
- 229 x 89 x 45 mm (for TDI module)1
- 138mm x 138mm x 70mm (for 3500/22M)2
- 9.50 x 4.50 x 1.00 inches (for 3500/22M in inches)3
- Weight:
- 1.8 kg (for TDI module)1
- 0.5 kg (for 3500/22M)2
- 0.85 lb (for 3500/22M in pounds)3
Features
- Flexibility and Scalability: Compatible with various Bently Nevada sensors and systems, with the ability to add additional channels1.
- Vibration Monitoring: Used in vibration monitoring systems to detect the vibration levels of rotating equipment such as generators, pumps, and fans45.
- Mechanical Health Monitoring: Monitors the mechanical health of rotating equipment to detect potential faults early5.
- Transient Data Recording: Captures and stores transient events for analysis5.
- Real-Time Monitoring: Provides real-time mechanical operating status for operators to monitor and respond5.
- Temperature Monitoring: Some models may include temperature monitoring capabilities6.
Role
- BENTLY 3500/22-01-01-00 is a transient data interface module manufactured by Bently Nevada. It serves as an interface between the 3500 monitoring system and compatible software (e.g., System 1 monitoring and diagnostic software and 3500 system configuration software)45. It combines the functionality of the 3500/20 rack interface module (RIM) and communication processors such as TDXnet to continuously collect steady-state and transient waveform data, which are then transmitted to host software over an Ethernet network
