Description
Bently 3500/05 Parameters, Specifications, Dimensions, Weight, Series, Features, and Functions
Parameters and Specifications:
System Compatibility: The Bently 3500/05 system rack is compatible with various 3500 monitoring modules and rack power supplies.
Communication: It allows modules to communicate with each other and distributes power to each module as needed.
Frame Sizes and Slots: Two frame sizes are available: a full-size 19-inch EIA frame with 14 available module slots and a mini frame with 12 inches and 7 slots.
Installation Options: Frames can be installed using panel, frame, or wall mount options.
Electromagnetic Compatibility (EMC): The system meets various EMC standards for radiation and conduction emissions.
Dimensions:
The exact dimensions of the 3500/05 system rack, including its length, width, and height, are not provided in the given search results. However, the rack’s size would depend on whether it’s the full-size or mini frame.
Weight:
The weight of the Bently 3500/05 system rack is approximately 2KG.
Series:
The 3500/05 rack belongs to the Bently Nevada 3500 series of monitoring and control systems.
Features:
Modular Design: Its modular design allows for easy installation, replacement, and expansion of modules.
Internal Safety Barrier: The rack supports an internal safety barrier module for grounding connections.
Flexibility: It offers flexibility in terms of power distribution and communication among various modules.
Functions/Role:
Monitoring and Control: The 3500/05 system rack serves as the backbone for industrial monitoring and control systems, enabling the collection, processing, and transmission of data from various sensors and devices.
Integration: It integrates various monitoring modules, such as vibration and displacement sensors, into a unified system for comprehensive monitoring and control.
Power Distribution: The rack distributes power to each module as required, ensuring reliable operation of the entire system.
Please note that the specific parameters, specifications, dimensions, and weight may vary depending on the configuration and any updates or modifications made by the manufacturer. It is always advisable to refer to the official documentation or contact the manufacturer for the most accurate and up-to-date information.
