Bentley 3500/42M

Description

Parameters and Specifications:

• Channels: 4-channel monitor¹²
• Input: Accepts input from proximity sensors and seismic sensors¹
• Input Impedance: 10kΩ (standard I/O)¹²
• Power Consumption: 7.7W¹
• Sensitivity (Radial Vibration & Axial Displacement): 3.94 mV/μm (100 mV/mil) or 7.87 mV/μm (200 mV/mil)¹²

Dimensions and Weight:

• Exact dimensions and weight are not provided in the search results. However, it is generally a compact module suitable for installation in a rack or panel.

Series:

• Bentley Nevada

Features:

• Multi-channel Monitoring: Can monitor up to 4 channels simultaneously¹².
• Versatile Input: Accepts input from displacement, speed, and acceleration sensors¹².
• Configurable: Each channel can be programmed using 3500 framework configuration software to perform various functions such as radial vibration, axial displacement, eccentricity, differential expansion, acceleration, speed, etc.¹².
• Alarm Comparison: Compares processed signals with user-programmable alarm values¹².
• Real-time Monitoring: Provides continuous monitoring and real-time data feedback³.
• Protection: Ensures protection of rotating machinery by triggering alarms when vibration levels exceed safety thresholds

Applications:

• Industrial Monitoring: Used in industrial environments to monitor vibration, position, and other parameters of rotating machinery such as engines, pumps, compressors, etc.³.
• Equipment Protection: Helps detect abnormal vibrations and take appropriate maintenance measures to ensure safe operation and extend equipment life³.
• Seismic Monitoring: Also capable of monitoring seismic events and triggering emergency shutdowns or protective measures in earthquake-prone areas
