ATV71HD45N4

Description

‌Series‌:

• The ATV71HD45N4 belongs to the Altivar 71 series of variable speed drives from Schneider Electric12.
  ‌Parameters‌:
• Power Rating: 45 kW / 60 HP12.
• Voltage Range: 380V to 480V14.
• Frequency Range: 50/60 Hz16.
  ‌Specifications‌:
• Output Frequency: 0.1 to 500 Hz4.
• Rated Switching Frequency: 2.5 kHz, with an adjustable range of 1 to 16 kHz4.
• EMC Filter: Integrated14.
• Assembly Style: With heat sink
  ‌Dimensions & Weight‌:
• Dimensions: Height 630mm, depth 290mm, width 320mm
• Weight: Approximately 44 kg
•
  ‌Features‌:
• Wide Voltage Range: Operates within a wide voltage range of 380V to 480V, allowing flexibility in system design14.
• Flux Vector Control: Offers flux vector control (FVC) with sensor and sensorless options for precise motor control1.
• Modbus Communication: Supports Modbus communication protocol for seamless integration with various automation systems1.
• Overload Protection: Equipped with overload protection features to safeguard the motor and drive during operation5.
• Energy Adaptation System: Features an ENA (Energy Adaptation) system for unbalanced loads, enhancing system efficiency1.
  ‌Role‌:
• The ATV71HD45N4 serves as a high-performance variable speed drive for controlling complex high-power machines14.
• It provides precise speed and torque control, enabling efficient operation of motors and machinery in various industrial applications15.
• Its advanced features, including flux vector control, overload protection, and energy adaptation, make it an ideal choice for demanding industrial environments
