AO2020

Description

‌Parameters & Specifications‌:

–‌Analysis Objects‌: Capable of analyzing multiple gas components such as CO, CO2, NO, SO2, NH3, H2O, CH4, and other hydrocarbons12.
–‌Measurement Range‌: Customizable based on application, with minimum ranges starting from 0-10ppm for CO and 0-5ppm for CO21.
–‌Accuracy‌: ±0.5% FS (full scale) linear error12.
–‌Response Time‌: Less than 3 seconds12.
–‌Power Requirements‌: Operates within a voltage range of 100-240VAC ±10% and a frequency of 48-63Hz12.
–‌Power Consumption‌: Approximately 40VA for single-channel and 70VA for dual-channel configurations12.
‌Dimensions & Weight‌:

–‌Dimensions‌: 483mm wide x 412(597)mm depth x 177mm height
–‌Weight‌: Varies depending on configuration, typically ranging from approximately 15kg for single-channel to 21kg for dual-channel

‌Series‌:

• Part of ABB’s AO2000 series of gas analyzers1.
  ‌Features‌:

–‌High Precision‌: Utilizes advanced infrared spectroscopy technology for accurate gas detection and analysis25.
–‌Multi-Gas Capability‌: Able to measure multiple gas components simultaneously2.
–‌Auto-Range Switching‌: Equipped with 4 measurement ranges and an auto-range switching function12.
–‌Stability & Reliability‌: Proven through rigorous quality control and testing, suitable for various industrial environments5.
–‌User-Friendly‌: Equipped with an intuitive user interface and simplified operation menu5.
–‌Maintenance-Friendly‌: Features automatic calibration and cleaning functions to reduce maintenance workload5.
‌Functions‌:

–‌Gas Analysis‌: Continuously measures the concentration of various gas components in gas or steam1.
–‌Environmental Monitoring‌: Used in environmental monitoring applications to ensure air quality and safety2.
–‌Industrial Process Control‌: Integral to industrial process control systems, providing real-time data for process optimization2.
–‌Energy Management‌: Supports energy management efforts by providing insights into gas emissions and consumption.
