AIP571 BUS1

Description

5.‌Features‌:
–‌High Reliability and Stability‌: Meets complex industrial control demands with high reliability and stability1
–‌Signal Filtering‌: Each channel includes an analog filter (6 ms) for improved signal quality2
–‌Input Status Indicators‌: LED indicators for each input channel, providing visual status confirmation2
–‌Alarm Function‌: Equipped with alarm capabilities for monitoring and fault detection2

6.‌Functions‌:
–‌Input Signal Processing‌: Processes analog and digital input signals from field devices2
–‌Control Signal Output‌: Although primarily an input module, it can be integrated into a larger control system, contributing to overall control strategies3
–‌System Integration‌: Seamlessly integrates with Yokogawa’s automation systems and other compatible equipment

1.‌Parameters‌:
–‌Communication Interface‌: RS485
–‌Communication Protocol‌: Modbus RTU1
–‌Input Channels‌: 8 channels for 120 VAC/DC input2
–‌Input Voltage Range‌: AC 77-130V, DC 75-145V2

2.‌Specifications‌:
–‌Design‌: Compact and robust, ensuring reliability and stability in industrial environments1
–‌Isolation‌: Each input channel is individually isolated, providing enhanced safety and protection2
–‌Voltage Monitoring‌: Capable of monitoring field input power voltage2

3.‌Dimensions & Weight‌:
–‌Dimensions‌: Specific dimensions are not provided, but it is designed for compactness.
–‌Weight‌: Approximately 2KG2

4.‌Series‌:

• Part of Yokogawa’s industrial automation controller series, specifically designed for industrial process control applications
