Description
Parameters and specifications:
Electrical interface: RJ45 to RS485.
Power supply: 24VDC.
Operating current consumption: ≥20nA.
Connected to a CPU: Yes (PPI communication port that occupies one CPU).
Support communication protocol: PPI protocol.
Cable length (shielded) : 100M when less than or equal to 19.2K.
Display indicator: Power +24V green light, BF red light, XT red light.
Operating temperature: 0-60 °C (or -25°C to +70°C, depending on the reference).
Storage temperature: -40°C to +85°C.
Relative humidity: 10% to 90% (no condensation).
Output frequency: 230.
Voltage and current: Input voltage 100-240VAC, output voltage 24VDC, output current 10A, maximum power 240W.
Resistance: 5 Ohms.
Current: 5A.
Voltage: 220V.
Size and weight:
Dimensions: 71 x 80 x 62 (or 150mm x 110mm x 50mm, depending on the reference).
Weight: 1.2kg.
Features:
Communication interface: Support Ethernet to PPI communication, you can use STEP 7Micro/WIN for remote configuration, programming and diagnosis.
Multi-function: can be used as a communication client or server, so that the CPU can communicate with other control systems or PCS through Ethernet.
Web Settings: You can set the internal parameters of the module through the web page.
High performance excitation control: advanced excitation control algorithm is used to ensure the stability and reliability of the motor during operation.
Multiple control modes: Support constant current control, constant voltage control and other excitation control modes.
Flexible communication interface: Support Ethernet/IP, Modbus TCP/IP and other communication protocols and interfaces.
Perfect protection function: over-current, over-voltage, under-voltage and other protection functions.
