Description
Parameters and Specifications:
Input Voltage: AC100-240V, DC48-250V
Frequency Range: 50/60 Hz
Operating Temperature Range: -40°C to +70°C
Protection Class: IP40 (front panel), IP30 (back)
Communication Interfaces: RS485, Ethernet, Modbus TCP/IP, IEC 61850
Dimensions and Weight:
Dimensions: 20011050mm
Weight: Not specified
Series:
RET650 Series
Features:
Powerful Relay Protection Terminal: Suitable for protection and control systems of high-voltage transmission lines and substations
Processor: On-board notebook low-power Pentium III-M / Celeron processor
Memory: On-board 256M memory, supports up to 768M with an additional 144 pin PC133 SODIMM memory module
I/O Interfaces: Includes IDE, RS-232 TTL, parallel, USB 2.0, PS/2 keyboard/mouse, and RJ-45 Ethernet
Expandable: Provides 1 PCI expansion slot
Supports Standards: IEC 61850
Functions and Applications:
ABB RET650 is a digital output module designed for automatic voltage regulation.
It provides fast and selective protection, monitoring, and control for various transformers, such as double-winding transformers, three-winding transformers, auto-transformers, shunt reactors, and booster transformers.
Features include low impedance restricted earth fault protection, multifunctional phase-to-phase, earth fault, positive sequence, and zero sequence overcurrent protection.
It can output pulse signals for pressure release, light and heavy gas, and excessive oil temperature through IED devices.
