Description
Parameters and specifications:
The REF615 supports multiple protection functions such as over current, over load, short circuit, ground fault, over voltage, under voltage, over frequency, under frequency, etc.
The device supports IEC61850 communication standards, including IEC 61850-9-2 LE, and also supports DNP3, IEC 60870-5-103 and Modbus® protocols.
The REF615 provides precise protection measurement with high-precision digital signal processing technology.
Size and weight:
The size is approximately 20011050mm, but please note that this is based on information from the ABB REF615 analog input module and the exact size may vary by model and configuration.
In terms of weight, the specific weight of the REF615 is not directly given, but ABB’s similar products such as the REF615E_G weigh 2KG.
Series:
The REF615 is a member of the 615 product family in ABB’s Relion® product family.
Features:
The REF615 features versatile protection to detect and protect power equipment comprehensively and effectively.
The high-speed circuit breaker control function enables it to quickly isolate faults and protect the safe operation of the power grid.
With flexible protection configuration capabilities, users can customize the configuration based on actual requirements.
The intuitive operation interface and visual operation interface make parameter setting and query easy.
Multiple communication protocol support enables the REF615 to exchange data with other smart devices and monitor them remotely.
Functions:
The REF615 is primarily used to protect, control, measure and monitor public and industrial power distribution systems.
It can be adapted to both neutral ungrounded power grids and neutral resistance or impedance grounded power grids.
The REF615 is suitable for annular mesh distribution networks or radiant network protection, where the protected grid contains multiple feeds and distributed generation.
