Description
ABB REF610C11LCLR is an industrial automation product designed for motor protection and system voltage monitoring. Here’s an overview of its parameters, specifications, dimensions, weight, series, features, and applications in English:
Parameters:
Input Voltage: Typically 24 V DC ± 20%.
Input Current: Maximum of 5 mA.
Output Type: Relay.
Specifications:
Word Input Quantity: 16 digits.
Word Output Quantity: 16 digits.
Processing Capability: REF610C11LCLR has strong processing capabilities, handling large amounts of data with high speed.
Dimensions and Weight:
Weight: Approximately 2KG.
Dimensions: Actual dimensions may vary depending on the module’s configuration and packaging. It is recommended to consult the official documentation or manufacturer for precise measurements.
Series:
ABB REF610C11LCLR belongs to the 610 product series of ABB Relion, specifically designed for feeder protection, motor protection, and general system voltage monitoring.
Features:
Motor Protection: REF610C11LCLR monitors the operating status of the motor and cuts off the power supply in case of faults or abnormalities, protecting the motor from further damage.
Arc Protection: Suitable for marine and offshore environments, it provides optional arc protection, responding quickly to arc faults on substation busbars.
Insertable Design: Its insertable design facilitates the debugging of switchgear equipment and allows for quick and safe insertion and removal of relay modules.
Ethernet Connectivity: REF610C11LCLR can also be used as an Ethernet port module, enabling the connection of ABB’s automation equipment or other related devices to the Ethernet for information transmission and interaction.
Role/Application:
ABB REF610C11LCLR motor protection relay is widely used in industrial automation scenarios. It’s primarily employed in the protection of resistance-grounded and solidly-grounded power systems in distribution substations, both incoming and outgoing feeders. Additionally, its features make it suitable for use in harsh environments and demanding applications where precision and reliability are crucial.
