Description
ABB PU516 is a highly versatile module that finds extensive application in industrial automation and control systems. Here’s a summary of its parameters, specifications, dimensions, weight, series, features, and applications in English:
Parameters and Specifications:
Design: The PU516 features a compact and sleek design, greatly reducing desktop footprint.
Display: It incorporates a 5.7” 64K-color TFT color liquid crystal display.
Sampling Rate: It offers a real-time sampling rate of 400 MSa/s and an equivalent sampling rate of up to 25 GSa/s, ensuring effective capture of real-time transient signals.
Storage Depth: The module provides a storage depth of 1M sampling points (single channel) and 512K sampling points (dual channel).
Dimensions and Weight:
Dimensions: The exact dimensions of the PU516 module may vary slightly based on the specific model. It is advisable to refer to the official documentation for precise measurements.
Weight: Typically, the module’s weight is around 0.3kg.
Series:
ABB PU516 belongs to ABB’s extensive line of industrial automation components, specifically designed for use in various control systems.
Features:
Versatile Input: PU516 supports a wide range of input types and functions, making it suitable for multiple applications.
Triggering Capabilities: The module offers advanced triggering functionalities, including edge, video, pulse width, slope, alternate, pattern, and duration triggers.
Measurement and Analysis: PU516 provides 20 types of automatic measurement functions and cursor measurement, including manual mode, tracking mode, and automatic measurement mode.
Communication Interfaces: Standard communication interfaces such as USB Device, RS-232, and USB Host are supported, enabling easy integration with other devices and systems.
Calibration and Filtering: The module features automatic calibration functionality and unique digital filtering and waveform recording capabilities.
Applications:
ABB PU516 is commonly used in industrial automation systems for monitoring and controlling various devices, machines, and processes. Its advanced triggering, measurement, and analysis capabilities make it suitable for applications that require precise signal processing and control.
