Description
The ABB PFEA111-20 is a device with a variety of functions and applications, the following are details about its parameters, specifications, dimensions, weight, series, features and role:
Parameters and specifications:
Operating voltage: Input voltage is 24vdc, output voltage is also 24vdc.
Output current: 2A.
Operating temperature: Its operating temperature range is wide, from -25℃ to +70℃.
Number of phases: 2.
Step accuracy: 5%.
Temperature rise: Max. 80K.
Operating temperature: 0℃ to +50℃.
Insulation class: B (130℃).
Insulation resistance: 100MΩMIN@500V DC.
Axial load: maximum 15N.
Radial load: 20mm at the exit shaft, maximum 75N.
Axial runout: Max. 0.02mm (under 450g load).
Radial runout: maximum 0.08mm (under 450g load).
Step Angle: 1.8.
Total length of motor: 76mm.
Holding torque: 2.0N.m.
Rated current: 5.0A.
Phase resistance: 0.40Ω.
Phase inductance: 1.7mH.
Rotor inertia: 480 grams per square centimeter.
Motor weight: 1.06kg.
Number of motor lines: 4.
Size and weight:
Size: 118.5mm x 68mm.
Weight: There are two statements, one is 0.15kg, the other is 0.2 kg. There may be slight differences in weight from batch to batch.
Series:
PFEA111-20 belongs to a family of ABB, the specific family name may require further inquiry.
Features:
Low noise, low vibration, low heat: to ensure the stability and reliability of equipment operation.
Multiple interfaces: Supports a variety of communication interfaces, such as CAN, Profibus, etc., to facilitate connection and communication with other devices.
High-precision control: Advanced control algorithms and sensor technology ensure that the tension in the production process remains stable.
Easy to operate: with a friendly user interface and operation mode, convenient for users to set parameters, view data and troubleshoot.
Energy conservation and environmental protection: with the characteristics of energy conservation and environmental protection, help to reduce energy consumption and reduce the impact on the environment.
Functions:
The PFEA111-20 is a functional module (1 axis) for simple positioning tasks, mainly for industrial automation and process control.
It is mainly used to control the tension of materials to ensure that the tension in the production process remains stable, and has a wide range of applications in a variety of industrial applications, including chemical treatment, water treatment, and food and beverage treatment.
