ABB IMHSS03

Description

Parameters and Specifications:

• Brand: ABB
• Model: IMHSS03
• Power Supply Voltage: 24V DC
• Rated Current: 5A
• Maximum Current: 10A
• Output Power: 120W
• Control Method: Analog/Pulse
• Response Frequency: 500Hz
• Accuracy: ±0.05%FS
• MTBF (Mean Time Between Failures): >10000 hours

Dimensions and Weight:

• Size: 100x60x30mm
• Weight: 0.5kg

Series:

• IMHSS Series – A series of hydraulic servo submodules within the ABB Bailey system¹.

Features:

• Compact and Lightweight: Small in size and light in weight¹.
• High Precision and Reliability: Utilizes advanced hydraulic servo technology for precise and reliable operation¹².
• High Response Speed: Capable of rapid response to external inputs and commands².
• Wide Range Speed Adjustment: Supports large range speed regulation to meet different application requirements².
• Safety Functions: Includes features to detect system abnormalities and trigger emergency stop or other safety measures².
• Interoperability: Able to exchange data with other devices such as supervisory systems or other control modules².

Role and Application:

• Valve Position Control: IMHSS03 is a hydraulic servo module commonly used for valve position control to regulate turbine speed²³.
• Precise Control: Integrates servo valves or motors with controllers to achieve precise speed and position control²³.
• Industrial Automation: Widely used in various industrial automation and control systems such as machine tools, robots, conveyor systems, and printing machines to enhance production efficiency and precision³.
