Description
The ABB DS200NATOG2A is a voltage feedback scale board commonly used in automation system equipment. The following is information about the detailed parameters, specifications, dimensions, weight, series, features and functions of this product:
Parameters and specifications:
Operating voltage: Usually 24VDC.
Data capacity: 4KB.
Processing speed: 10 MHZ.
Ambient temperature: 0 to 6 degrees Celsius.
Ambient humidity: 0%-95% non-condensing.
Product certification: Meets UL standards.
Size and weight:
Dimensions: The overall dimensions are 8.8 x 3.6 x 4.7 inches.
Weight: Approximately 1.2kg (weight may vary depending on batch and configuration).
Series:
It is part of ABB’s range of voltage feedback proportional boards, particularly in the AC drive series.
Features:
Voltage feedback scaling: The DS200NATOG2A can accurately feedback and scale the voltage to meet the different control requirements in the automation system.
Modular design: Easy to install and configure, and can work with other modules to achieve complex control logic.
Multiple outputs: Outputs are obtained by five wires connected to 20-pin ribbon joints for connecting different control devices and systems.
Metal oxide rheostat: prevents the output voltage from being too high when the strip circuit is interrupted when the input voltage is present.
NATO Committee certification: Meets CSA/UL/EC standards to ensure product safety and reliability.
Functions:
Voltage Monitoring and control: The DS200NATOG2A is used to monitor and control voltage signals to ensure voltage stability and precise control in automated systems.
System integration: As part of the automation system, it communicates and integrates with other devices and control systems to achieve the collaborative work of the entire system.
Improve system performance: With precise voltage feedback and scaling, the DS200NATOG2A helps improve system performance and stability.
