ABB CS513 3BSE000435R

Description

dav

Parameters and Specifications:

• Model: CS513 3BSE000435R1
• Communication Protocol: IEEE 802.3, PROFIBUS DP, MODBUS RTU, ASCII¹²
• Transmission Rate: 10/100 Mbps (IEEE 802.3), 12 Mbps (PROFIBUS DP), 115.2 kbps (MODBUS RTU and ASCII)¹²
• Interface Type: RJ45 (Ethernet), RS-232, RS-485¹²
• Power Supply: 24 V DC¹
• Operating Temperature: -20°C to +60°C (some sources mention -40°C to +70°C)¹²
• Dimensions: 225mm x 140mm x 70mm³
• Weight: Approximately 2 kg¹³⁴
• Safety Rating: SIL 3³

Series:

• The CS513 3BSE000435R1 is part of the ABB AC800PEC series¹.

dav

Features:

• High Performance: Provides high-speed communication with up to 100 Mbps data transmission rate (IEEE 802.3)¹.
• Multi-Communication Interface: Supports Ethernet, serial communication interfaces (e.g., RS-232, RS-485), and industrial communication protocols (e.g., Modbus, Profibus)².
• Ease of Use: Supports automatic negotiation of transmission rate and duplex mode, enabling plug-and-play operation¹.
• High Reliability: Redundant design and fault diagnosis functionality³.
• Wide Applicability: Suitable for various industrial applications, including oil and gas, chemical, power, nuclear energy, etc.³⁴.

dav

Role and Applications:

• The ABB CS513 3BSE000435R1 is a communication module designed for ABB Advant Master series control systems²⁵.
• It provides high-speed communication between the Advant Master system and other devices such as field instruments, controllers, and other systems²⁵.
• It is used to execute control logic, data acquisition, communication, and data processing tasks in industrial automation and control systems²⁶.
• It can be applied in various applications, including distributed control systems, SCADA systems, and process automation².
