Description
Parameters and specifications:
Protocol: Supports protocols such as Modbus TCP.
Transmission speed: 10/100 Mbit/s (Ch1), 10 Mbit/s (Ch2).
Hot swap: Supported.
Connector: RJ-45 female (8 pins).
Environmental data: Operating conditions 0 to +55°C (storage -40 to +70°C), protection class IP20, compliance with G3 corrosion protection, compliance with EMC Directive 2004/108/EC, passing EN 61000-6-4 and EN 61000-6-2 EMC tests, Comply with UL508, IEC/EN 61131-2 electrical safety standards, suitable for UL/CSA 60079-15 hazard classification sites.
Size:
Net depth/length: 185mm.
Product height: 127.5mm.
Product net width: 59 mm or 60mm (may vary according to the specific version).
Weight:
Net weight: 0.621 kg.
Series:
The CI867K01 is part of ABB’s AC 800M controller family or similar series.
Features:
Communication interface: Provides Modbus TCP interface.
High precision: High current generator, high precision sensor and high performance 14-bit AD acquisition chip.
Easy to operate: touch panel button operation, all functions are set by the button.
Versatility: Support automatic upflow test, manual upflow test and impact quick break test.
Overcurrent protection: can set the target output current value, current upper limit and current resistance time, exceed the set value will automatically return to zero and alarm.
Strong anti-interference: the combination of hard and software anti-interference technology to adapt to the harsh electromagnetic environment.
Functions:
Industrial automation: Used to communicate with other automation equipment, control systems or sensors for industrial automation and integration.
Process control: used to monitor and control various processes, such as chemical plants, power plants, pharmaceutical plants, etc.
PLC system: Integrated into the PLC system, used to communicate with other PLC modules or external devices, to achieve centralized management of the entire control system.
Data acquisition and monitoring: The acquisition of data from various sensors and devices and the transmission of this data to the monitoring system for real-time monitoring and analysis.
Remote monitoring and operation: Support for remote monitoring and operation enables operators to monitor and control production processes from different locations.
