Description
ABB 5SHY4045L0004: Parameters, Specifications, Dimensions, Weight, Series, Features, and Applications (English)
Parameters:
Rated Voltage: 380V-400V.
Rated Current: 45A.
Short-Time Tolerant Current: 1.5kA.
Specifications:
Mechanical Life: 1,000,000 times.
Protection Features: Overload, short-circuit, and undervoltage protection.
Dimensions and Weight:
Dimensions: 450x250x300mm.
Weight: 15kg.
Series:
ABB 5SHY4045L0004 belongs to the series of high-performance electronic components and modules designed by ABB for various industrial applications.
Features:
High Reliability and Durability: The module is designed for reliable performance and long-term durability, suitable for harsh industrial environments.
Versatile Applications: It can be used in a wide range of industrial automation and control systems, including switching logic control, process control, motion control, data processing, and communication.
SPT (Soft Through) Chipset: Features SPT and SPT++ chipsets for high output power and rated current with moderate chip area.
High-Temperature Operation: The 1700 V SPT++ chipset allows for operable connection temperatures up to 175°C, enhancing power density and module design flexibility.
Easy Expansion: Supports simple expansion through EtherCAT (FSoE) for up to 30 fault-safe inputs or outputs.
Applications:
Industrial Power Conversion and Drives: Used in traction, wind turbine converters, renewable energy sources, and industrial drives.
Power Systems: For applications in FACTS (Flexible AC Transmission Systems).
Renewable Energy: Such as solar and battery power converters.
Backup Systems (UPS): Provides uninterrupted power supply for critical equipment.
Programming and Monitoring: Enables easy project planning, safe logic execution, and safety monitoring with graphical programming tools and encoders.
