Description
ABB’s 5SHY3545L0016 3BHB019719R0101 GVC736BE101 5SXE06-0160 is a high-performance Asymmetric Integrated Gate-Controlled Thyristor (IGCT) module specifically designed for high-power applications. Here are the key parameters, specifications, dimensions, weight, series, features, and functions of this component in English:
Parameters:
Maximum Rated Current: 3500 A
Maximum Rated Voltage: 4500 V
Maximum Rated On/Off Loss: 14000 W
Maximum Rated Switching Frequency: 1600 Hz
Maximum Rated Junction Temperature: 175°C
Minimum Rated Gate Pulse Current: 10 mA
Minimum Rated Gate Pulse Voltage: 15 V
Specifications:
Module Packaging: TO-247AB
Module Weight: Approximately 3.5 kg
Cooling Method: Water cooling
Dimensions and Weight:
While the exact dimensions of the module are not provided, it’s generally designed for modular integration, often with a compact footprint.
The approximate weight is mentioned as 3.5 kg.
Series:
This module belongs to ABB’s 5SHY series of IGCT products.
Features:
Asymmetric Structure: Enhances switching efficiency.
Advanced Chip Manufacturing: Ensures reliability and durability.
Comprehensive Protection: Ensures safety and enhances the module’s lifespan.
RoHS Compliant: Environmentally friendly and safe.
Functions/Applications:
High-Power Switching: The module is designed for high-power switching applications, such as power transmission and distribution, renewable energy generation, power transmission systems, and industrial control systems.
Voltage and Current Control: Its high current and voltage ratings allow for precise control of electrical systems.
Energy Efficiency: With low losses and high efficiency, it helps optimize energy usage in power systems.
