ABB 3HNA025019-001

Description

Parameters and Specifications:

• Model/Series: ABB 3HNA025019-001¹²³⁴
• Input/Output: Two switch outputs, one with IO-Link communication interface¹
• Measurement Range: 0…600 bar; 0…8700 psi; 0…60 MPa¹
• System Interface: Threaded connection G 1/4 internal thread¹
• Special Performance: Gold-plated contacts¹
• Material of Measuring Element: Metal diaphragm¹
• Applications: Industrial applications¹
• Media: Liquid and gas media¹
• Operating Temperature Range: -25…80°C¹
• Storage Temperature Range: -40…100°C¹
• Enclosure Protection Class: IP 65; IP 67¹
• Weight: 231.5g¹
• Materials Used: 1.4542 (17-4 PH / 630), stainless steel (1.4404 / 316L), PBT+PC-GF30, PBT-GF20, PC¹
• Working Voltage: 18…30 DC¹
• Current Consumption: < 35 mA¹
• Output Signal: Switch signal; IO-Link (configurable)¹
• Electrical Design: PNP/NPN¹
• Switch Frequency DC: < 170 Hz¹
• Reaction Time: < 3 ms¹

Features:

• Dual Switch Outputs: Provides flexibility in system design and integration¹.
• IO-Link Communication: Enables data exchange and remote monitoring¹.
• High Overload Protection and Stability: Ensures durability and longevity in harsh industrial environments¹.
• Gold-plated Contacts: Provides superior electrical conductivity and corrosion resistance¹.
• Rotatable Connection: Allows for optimal piping arrangement¹.

Role and Function:

ABB 3HNA025019-001 is a DCS (Distributed Control System) controller module designed for industrial applications. It offers two switch outputs, one of which supports IO-Link communication, enabling data exchange and remote monitoring. The module features high overload protection, long-term stability, and a robust design suitable for harsh industrial environments. It is commonly used in steel manufacturing, papermaking, petroleum, thermal power generation, and hydropower generation industries²³.
