Description
Parameters and Specifications:
Maximum Rated Current: 3500 A
Maximum Rated Voltage: 4500 V
Maximum Rated Switching Loss: 14000 W
Maximum Rated Switching Frequency: 1600 Hz
Maximum Rated Junction Temperature: 175°C
Minimum Rated Gate Pulse Current: 10 mA
Minimum Rated Gate Pulse Voltage: 15 V
Number of Dies: 1
Cooling Method: Water Cooling
Dimensions and Weight:
Module Package: TO-247AB
Module Weight: Approx. 3.5 kg
Outer Dimensions (of the 5SHY3545L0010 Series Inverter): 267mm x 167mm x 127mm, Weight Approx. 11kg
Note: The dimensions and weight provided for the inverter series may not be exact for the ABB 3BHB013088R0001 module, but can serve as a general reference.
Series:
5SHY Series IGCT Product Series
Features:
High Power Handling: Capable of handling high currents and voltages, suitable for various applications.
Rapid Switching Speed: Provides fast switching speed for efficient control of large power devices.
Current and Voltage Control: Allows for precise control of current and voltage in electrical systems.
Protection Mechanisms: Includes current and voltage limitation to ensure safe operation.
Communication Interface: Equipped with communication interfaces for integration with other control systems.
Remote Control and Monitoring: Supports remote upload, download, gateway health self-diagnosis, VPN, network redundancy, and other advanced features.
Applications:
Used in power transmission and distribution, renewable energy generation, power drive systems, and industrial control applications.
Allows for virtual engineering and debugging, enabling manufacturers and integrators to develop and simulate entire industrial processing lines and machines without the need for actual hardware.
