Description
Features:
User-configurable on-time for switching frequencies up to 2.0 MHz
The brightness control is realized by PWM of DIS pin
Few external components required
Wide input voltage range: 9 to 46 V
Low 0.18V induction voltage for improved efficiency
No-output capacitor
Heat off protection
Package with enhanced heat dissipation capability
Parameters and specifications:
Number of features: 1
Number of terminals: 16
Maximum operating temperature: 105°C
Minimum operating temperature: -40°C
Max supply voltage: 146 V
Minimum supply voltage: 19 V
Rated supply voltage: 112 V
Processing package: 4 x 4 mm, 0.75 mm HEIGHT, LEAD FREE, EIAJ, MO-220WGGC, QFN-16
Output current: up to 3.0A
Switching frequency: up to 2.0 MHz
Standby current: < 100μA
Size and weight:
Package size: 4 mm x 4 mm x 0.75 mm
