Description
Parameters and Specifications:
Sensor: 1/1.4″ CMOS
Resolution: 2352 x 1726 pixels (16 MP)12==
Pixel Size: 7.0μm x 7.0μm
Frame Rate: Up to 96 fps (8-TAP mode), 48 fps (4-TAP mode)
Exposure Time: 0.05μs to 170 ms
Pixel Depth: 8/12/14 bits
Interface: Camera Link1 or Gigabit Ethernet
Dimensions and Weight:
Dimensions: 44 x 44 x 29 mm1 or 29 x 29 x 41 mm(depending on source)
Weight: 100 g
Series:
The A404K belongs to the Basler Ace series, known for its excellent performance, reliability, and cost-effectiveness.
Features:
High Resolution: Provides clear and detailed images with 16 MP resolution.
High Speed: Capable of capturing images at up to 75 frames per second, enhancing productivity.
Low Noise: Ensures better image quality in low-light conditions.
High Sensitivity: Equipped with an advanced CMOS sensor for low-light applications.
Wide Dynamic Range: Captures images with both bright and dark areas simultaneously.
Applications:
Machine Vision and Automation: Ideal for automated production and assembly tasks, such as product identification and positioning.
Quality Control and Inspection: Used on production lines to check product appearance, dimensions, and defects.
Medical Imaging: Supports medical image capture and analysis in medical devices.
Scientific Research: Useful for capturing images and collecting data in scientific experiments.
Other Applications: Includes barcode/QR code scanning, traffic monitoring, and more.
