Description
series
Series: 505E series digital control equipment belonging to Woodward Company
trait
Load sharing: Features synchronous and droop load sharing to adjust the load when two or more generators are in parallel
Vibration resistance: can withstand the acceleration of 6.8G super vibration, work to ensure a wider temperature range (-40℃ ~ +85℃)
Environmental adaptability: The operating temperature range is -40 to 70 degrees Celsius (or -40 to 158 degrees Fahrenheit), and it can resist up to 40G of impact force at an 11-millisecond sawtooth pulse
Standard size design: easy to install into acceptable units
Parameters and specifications
Input voltage: 24VDC (although it is also mentioned that the voltage range is between 18 and 32VDC)
Output voltage: -0.6V DC is mentioned, but may vary from source to source
NVRAM: 8 KB
Voltage range: 220VDC (but more common range is 18 to 32VDC)
Diagnostic bus: 2 Mbps HDLC
Size and weight
Dimensions: 166mm x 112mm x 36mm
Weight: about 375g
effect
Main role: It provides a variety of functions and regulatory capabilities for its connected industrial generator systems, such as synchronization and droop load sharing
Application: Suitable for industrial applications such as construction machinery, agricultural machinery and machine tools
