Description
trait
Redundancy design: Usually has a redundancy design, can be used with other redundant modules, to achieve power backup and automatic switching, support dual redundancy high-speed fault-tolerant Ethernet LAN.
Diagnostic function: With diagnostic function, you can monitor the status and health of the power supply, and provide fault diagnosis and alarm functions.
Safety protection: with a variety of safety protection functions, such as over-current protection, overload protection, over-voltage protection and short circuit protection.
High-speed data transfer: Supports high-speed data transfer and can communicate with up to 64 I/O modules.
Flexible configuration: It can be configured and reconfigured online and supports point-to-point communication with standard controllers.
Modular design: easy to expand and maintain, you can choose different input and output modules and function modules according to actual needs.
argument
Interface type: LC1
Transmission rate: 10/100/1000Mbps
Working wavelength: 1310nm
Transmit power: -9.5dBm~0dBm
Receiving sensitivity: -20dBm
Maximum transmission distance: 10km
Operating temperature: According to different data, there are two ranges of -40°C to 85 °C and -40°C to 70°C
Power supply: 3.3V or 12V DC (depending on the application), there is also mention of 24VDC or 125VDC as the input voltage, and the output voltage is 24VDC
specification
Compatibility: complies with IEEE802.3z standard
Safety Certification: SIL 2 safety application certification, in accordance with IEC 61508 standard
Size and weight
Size: According to different data, there are 57mm x 14.5mm x 13.4mm and 120mm x 60mm x 80mm two sizes.
Weight: It is mentioned that the weight of the product is 0.5kg, but other specific weight information is not directly given.
