8200-226

Description

1.‌Parameters‌:

• Input Voltage: Typically 12VDC (though some sources mention 24VDC input)12
• Output Voltage: Depending on the configuration, it can output 10VDC or 0-20mA13
• Maximum Output Current: 2A1

2.‌Specifications‌:

• Designed for industrial automation, aerospace, marine, and military applications12
• Wide operating temperature range: -40°C to 85°C12
• Compliant with MIL-STD-202G, EN61326-1, EN61000-6-2, and UL 508 standards12

3.‌Dimensions & Weight‌:

• Dimensions: 2.0″ x 2.0″ x 0.5″ (50.8mm x 50.8mm x 12.7mm)12
• Weight: 0.1 lbs (approx. 45.4g)12

4.‌Series‌:

• Part of Woodward’s 8200 series of controllers4

5.‌Features‌:

• Stable output voltage even in harsh environments1
• Advanced switching power technology for high efficiency, low noise, and low interference2
• Overvoltage, overcurrent, and short-circuit protection2
• Compatible with DeviceNet or 4-20mA position demand signals5
• Windows-based software for configuration, adjustment, and remote monitoring5

6.‌Applications‌:

• Used in servo motor control systems, requiring precise positioning and speed control5
• Ideal for high-demand applications in industries such as industrial automation, aerospace, marine, and military12

7.‌Additional Notes‌:

• Always refer to the official Woodward documentation or contact the manufacturer for the most accurate and up-to-date information on the 8200-226’s specifications, features, and applications.
• This module’s versatility and robust design make it an excellent choice for critical applications requiring reliable power management and servo control.
