5X00481G04

Description

‌Parameters‌:

Signal Type: 4-20 mA current
Resolution: 16 bits
Sampling Rate: 250 Hz
Input Impedance: 250Ω
Power Supply Voltage: 24 VDC
Power Consumption: <10 W

‌Specifications‌:

Measurement Range: -1 to +100 bar
Accuracy: 0.15%
Stability: 0.05% of full scale per year

‌Dimensions and Weight‌:

Module Size: 270 x 173 x 40 mm
Module Weight: 2.4 kg
(Note: There’s also another mention of size as 600mm x 400mm x 200mm and weight as 50kg, which may refer to a different model or application)

‌Series‌:

It belongs to the Emerson Ovation HART Analog I/O Module Series

‌Features‌:

Converts 4-20 mA current signals from field devices into digital signals for processing by controllers or other equipment
High precision and reliability with redundant design and fault tolerance mechanisms
IP66 or IP67 enclosure protection rating, suitable for harsh industrial environments

‌Applications‌:

Can be used in various industrial applications, including pressure measurement in oil and gas, chemicals, power, water treatment, and food and beverage industries
Also used as an intelligent relay protection device in medium-voltage distribution systems, providing multiple protection functions such as overcurrent, short circuit, overvoltage, undervoltage, frequency, power, differential, and zero-sequence harmonic protections
