5X00070G04

Description

Parameter Specifications

1. Power Supply
   The 5X00070G04 typically operates on a 24V DC power supply. Its power consumption is relatively low, around 8 – 12W, which is energy – efficient for continuous operation in industrial applications.
2. Input/Output Channels
   • Digital Inputs: It is equipped with 8 digital input channels. These inputs are designed to interface with common digital sensors such as proximity sensors, limit switches, and photoelectric sensors. The input voltage range is 18 – 30V DC.
   • Digital Outputs: There are 4 digital output channels. Each output channel can handle a resistive load of up to 1.5A and an inductive load of up to 0.8A, suitable for controlling relays, solenoid valves, and small – sized motors.
3. Communication Interface
   The 5X00070G04 supports the Modbus RTU communication protocol over an RS – 485 interface. The communication speed can reach up to 9600 bps, enabling efficient data exchange with other devices in an industrial network, like Programmable Logic Controllers (PLCs), Human – Machine Interfaces (HMIs), and Supervisory Control and Data Acquisition (SCADA) systems.

Uses

1. Industrial Automation
   • In small – to – medium – scale manufacturing plants, the 5X00070G04 can be used to monitor and control simple production processes. For example, it can detect the presence of workpieces on a small conveyor using digital inputs and control the start/stop of a single – stage processing machine via digital outputs.
2. Building Automation
   • In small commercial buildings or specific areas within larger buildings, it can manage basic building functions. It can be connected to door sensors and occupancy sensors to control the lighting in a small room or the operation of a single ventilation fan.
3. Agricultural Automation (Small – Scale)
   • In small – scale agricultural facilities, it can monitor environmental parameters such as the opening and closing status of greenhouse vents through connected sensors and control small – scale irrigation valves accordingly.

Weight and Dimensions

1. Weight
   The 5X00070G04 weighs approximately 0.7 – 1 kg, which is relatively light, making it easy to install and handle.
2. Dimensions
   It has a compact design with dimensions around 120mm (length) x 90mm (width) x 35mm (height). This small size allows it to be installed in standard control cabinets or on DIN rails without taking up much space.

Characteristics

1. Cost – Effective Solution
   The 5X00070G04 offers an affordable option for small – scale automation projects. It provides essential input/output and communication capabilities at a reasonable price.
2. Easy Configuration
   The device can be easily configured using simple software tools. Users can set up input/output parameters, communication settings, and diagnostic functions without complex programming knowledge.
3. Electrical Isolation
   It features electrical isolation between input/output channels and the power supply. This helps prevent electrical interference and protects the device and connected equipment from damage.

Stability and Reliability

1. Robust Construction
   The 5X00070G04 has a durable housing that can withstand normal industrial vibrations, dust, and moderate temperature variations.
2. Fault Protection
   It is equipped with over – current and over – voltage protection circuits. These safeguard the device from electrical faults, ensuring reliable operation over time.
3. Long – Term Testing
   The device has undergone long – term testing under various operating conditions to verify its stability and reliability, giving users confidence in its performance.
