5SHX1060H0003

Description

Parameter Specifications

1. Power Ratings: The 5SHX1060H0003 is a high – power semiconductor device, typically a thyristor. It has a blocking voltage capability of up to 4500V, which allows it to handle high – voltage applications. The continuous current – carrying capacity is around 1000A, enabling it to manage large – scale power flows.
2. Gate Triggering: It requires a specific gate – triggering condition. The gate trigger current is in the range of 100 – 200mA, and the gate trigger voltage is approximately 3 – 5V. Precise gate triggering is essential for proper device operation.
3. Thermal Characteristics: The device has a defined thermal resistance. The junction – to – case thermal resistance () is about 0.03 – 0.05 °C/W. This parameter is crucial for heat dissipation design to keep the device within a safe temperature range during operation.
4. Surge Current Capability: It can withstand high – amplitude short – term surge currents. The peak surge current rating is up to 10kA, which helps the device handle sudden current spikes without damage.

Applications

1. Power Conversion: In high – power AC – DC or DC – AC converters, such as those used in industrial motor drives, the 5SHX1060H0003 can be employed to control the power flow and perform efficient energy conversion.
2. High – power Switching: In electrical power distribution systems, it can serve as a high – power switch to control the connection and disconnection of large – scale electrical loads, such as in substations for grid management.
3. Electrometallurgical Processes: In industries like aluminum smelting or steelmaking, where high – power electrical currents are required for electrolysis or melting processes, the device can regulate and control the power supply.

Weight and Dimensions

1. Weight: Approximately 2 – 3 kg, depending on the specific packaging and cooling arrangements.
2. Dimensions: It has a relatively large and robust design. The main semiconductor module may have dimensions of about 120mm (length) x 100mm (width) x 60mm (height), excluding any additional cooling fins or mounting hardware.

Features

1. High – power Handling: Its ability to handle high voltages and currents makes it suitable for heavy – duty industrial applications where large amounts of electrical power need to be controlled.
2. Fast Switching Speed: It can switch on and off relatively quickly, which is important in applications where rapid changes in power flow are required, such as in pulse – width modulation (PWM) control systems.
3. Reliable Gate Triggering: The well – defined gate – triggering characteristics ensure consistent and reliable operation, reducing the risk of mis – triggering or device failure.

Stability and Reliability

1. Robust Construction: Built with high – quality semiconductor materials and a durable packaging, it can withstand mechanical stress, vibrations, and thermal cycling commonly encountered in industrial environments.
2. Thermal Management: The low thermal resistance and proper heat – dissipation design help maintain the device at a stable operating temperature, which is crucial for long – term reliability.
3. Quality Testing: Manufacturers conduct extensive quality testing on the 5SHX1060H0003, including electrical performance testing, temperature cycling tests, and reliability growth testing, to ensure its stability and reliability over a long service life.
