Description
ABB 3HNA025019-001 is an industrial automation control module, its specific parameters, specifications, size, weight, series, characteristics and functions are as follows:
Parameters and specifications:
Measuring range: 0… 600 bar, 0… 8700 psi, 0… 60 MPa.
System interface: threaded connection G 1/4 internal thread.
Working voltage: 18… 30 DC V.
Output quantity: 2.
Output signal: switching signal, IO-Link (configurable).
Electrical design: PNP/NPN.
Switching output DC voltage drop Maximum: 2.5V.
Continuous current load of switching output DC: 150 mA (200 mA @ 60 °C); 250 mA @ 40 °C.
Short circuit protection: Yes, the type is pulse.
Overload protection: Yes.
Response time: < 3 ms.
Ambient temperature: -25… 80 °C.
Storage temperature: -40… 100 °C.
Shell protection level: IP 65, IP 67.
Size and weight:
Weight: Approximately 231.5g.
Series:
The module is part of ABB’s industrial automation portfolio.
Features:
Two switching outputs: one with an IO-Link communication interface for easy communication with the upper computer or other devices.
Red/green display: Clearly identifies the acceptable range for quick status identification.
Pipe connections are rotatable: convenient for optimal alignment to suit different installation environments.
High load protection and long-term stability: Ensure that the module is stable in harsh industrial environments.
Rugged design: Suitable for harsh industrial environments with high durability and reliability.
Functions:
Industrial Automation Control: As a key component of the industrial automation control system, the ABB 3HNA025019-001 module is used to achieve communication and data transmission between devices, support real-time control requirements, and improve the efficiency and stability of industrial production.
Data acquisition and monitoring: Through its switching output and IO-Link communication interface, real-time monitoring and data acquisition of field equipment can be realized, providing real-time operating status and fault information for operators.
