3HAC024385-001

Description

trait
Dual bus and dual optical fiber interface: supports independent dual bus electrical interface and two optical fiber interfaces, which can form an optical fiber self-healing ring network.
Redundancy function: Provides redundant dual bus structure and optical fiber redundancy ring network function, suitable for redundant dual network system.
Flexibility: Support point-to-point, star, chain, bus, ring and hybrid network structure, can flexibly configure the interface according to the actual needs of the project.
Long-distance transmission: The optical fiber transmission distance is more than 20km, breaking the distance limit of the cable system.
Installation method: Support 35mmDIN rail installation.
effect
Signal conversion: Realize the conversion of electrical signals and optical fiber signals of Profibus DP bus.
Network expansion: The distance and range of the Profibus DP network can be extended through the fiber optic interface.
System redundancy: In a dual-network redundancy system, only one of the devices can be placed to improve the reliability and stability of the system.

Parameters and specifications
Category: Fieldbus, especially for Profibus.
Brand: Shenzhen Xunji Technology Co., Ltd.
Function: Support Profibus DP bus, realize the conversion of electrical signal and optical fiber signal, provide redundant dual bus structure and optical fiber redundancy ring network function.
Rate: Supports 10 common rates of the Profibus DP bus, the rate can be set by the dip switch or select the rate adaptive setting.
Size and weight
Size: The overall size is 132mm105mm52mm.
Weight: 800g net weight.
