3BSE042235R2

Description

‌Parameters & Specifications‌:

*‌Model‌: 3BSE042235R2 PP845A
*‌Manufacturer‌: ABB
*‌Voltage‌: Typically operates with a rated control circuit voltage of 18-30 V DC (including tolerances and residual voltage), with a 24 V DC option for specific terminals (A1/A2)1.
*‌Current‌: Control power current of typically 110 mA, with a maximum continuous current of 6 A for ring-through paths1.
*‌Protection‌: Includes protection circuits within the working voltage limits1 and short-circuit protection1.
‌Dimensions & Weight‌:

*‌Dimensions‌: Approximate dimensions are 200mm x 410mm x 10mm2, but it’s important to note that these dimensions might refer to the panel or housing, not necessarily the module itself.
*‌Weight‌: Mentioned as 2KG in some listings34, but it’s advisable to check the official documentation for exact weights.

‌Series‌:

• Part of ABB’s industrial automation product line, specifically related to control and display panels.
  ‌Features‌:

*‌High Integration‌: Offers high integration of I/O modules, including SIL3 certification5.
*‌Communication‌: Supports communication protocols such as HART or Profibus/FF, enabling real-time connections between field devices and control rooms6.
*‌Display‌: Equipped with status indicators, including 3x green LEDs and 1x red LED for monitoring1.
*‌Safety‌: Complies with safety regulations such as EN60950 and CE LVD2.
*‌Accuracy‌: Designed for high precision and accuracy in various industrial control applications5.
‌Functions‌:

*‌Control & Display‌: Primarily used as a control and display panel for industrial automation systems.
*‌Monitoring‌: Monitors system status through LED indicators and provides real-time feedback.
*‌Parameter Adjustment‌: Allows for parameter adjustment through communication interfaces, enhancing system flexibility and adaptability6.
*‌Safety & Reliability‌: Ensures system safety and reliability through protection circuits, short-circuit protection, and compliance with international safety standards
