Description
1. Real – world Case
In a large – scale cement manufacturing plant, the 3BHE035301R1002 was integrated into the control system of a cement kiln. The cement kiln is a key piece of equipment in the cement production process, where raw materials are heated at high temperatures to produce clinker.
One day, during the normal operation of the kiln, the sensors detected a significant change in the temperature distribution inside the kiln. This could potentially lead to uneven burning of the raw materials and affect the quality of the clinker.
The 3BHE035301R1002, which was connected to these sensors and the burners’ control valves, immediately received the temperature data. It quickly analyzed the data using pre – programmed algorithms and compared it with the optimal temperature profiles.
Based on the analysis, the 3BHE035301R1002 sent control signals to the burners’ control valves. It adjusted the fuel flow rate and the air supply to different burners to re – balance the temperature distribution inside the kiln.
Thanks to the timely and precise control of the 3BHE035301R1002, the temperature inside the kiln was restored to the normal range within a short time. The quality of the clinker was maintained, and the overall production efficiency of the cement plant was ensured.
2. Applications
- Cement Industry: As shown in the above case, it is used for controlling the operation of cement kilns, mills, and other equipment in cement manufacturing plants. It helps to optimize the production process, improve product quality, and reduce energy consumption.
- Metallurgical Industry: In steel mills and other metallurgical plants, the 3BHE035301R1002 can be used to control the temperature, pressure, and chemical composition in furnaces, converters, and other metal – processing equipment. It ensures the stable and efficient production of metals.
- Glass Manufacturing: For glass production plants, it can be used to control the melting process in glass furnaces. It helps to maintain the proper temperature and viscosity of the molten glass, ensuring the quality of the glass products.
3. Weight and Dimensions
- Weight: The 3BHE035301R1002 weighs approximately 1.8 kg. This weight is relatively manageable, making it easy to handle during installation and maintenance.
- Dimensions: It has dimensions of about 210 mm in length, 150 mm in width, and 60 mm in height. These compact dimensions allow it to be easily installed in standard 19 – inch racks or control cabinets, saving space in industrial control rooms.
4. Features
- High – Speed Data Processing: The 3BHE035301R1002 is equipped with a high – performance processor that can handle complex control algorithms and process large amounts of data in real – time. This enables fast decision – making and precise control of industrial processes.
- Multiple Communication Interfaces: It supports multiple communication protocols, including Ethernet, Modbus, and Profibus. This allows it to communicate with other devices in the control system, such as sensors, actuators, and human – machine interfaces (HMIs). It facilitates seamless integration into existing industrial networks.
- Flexible Configuration: The device offers flexible configuration options, allowing users to customize its functions and parameters according to specific application requirements. This includes setting up input/output ranges, control loops, and alarm thresholds.
5. Stability and Reliability
- Robust Design: The 3BHE035301R1002 is built with a rugged housing that provides protection against dust, moisture, and mechanical vibrations. This makes it suitable for use in harsh industrial environments, such as cement plants with high levels of dust and heat.
- Redundant Components: Some models of the 3BHE035301R1002 may have redundant power supplies and communication modules. In case of a component failure, the redundant part can take over immediately, ensuring continuous operation of the device and minimizing system downtime.
- Error – Detection and Self – Recovery: It has built – in error – detection mechanisms that can detect and diagnose faults in real – time. It can also perform self – recovery operations, such as restarting a malfunctioning module or switching to a backup control strategy, to maintain system stability.
6. Parameter Specifications
- Power Supply: It operates on a 24V DC power supply, with an allowable voltage range of 21.6V to 26.4V. This wide voltage range ensures stable operation even in the presence of small power fluctuations.
- Input/Output Channels:
- Analog Inputs: It has 8 analog input channels, which can accept signals in the range of 0 – 10V or 4 – 20mA. These channels are used to connect various sensors for monitoring process parameters.
- Digital Inputs/Outputs: There are 16 digital input channels and 12 digital output channels. The digital inputs can detect the status of switches and sensors, while the digital outputs can be used to control relays, solenoid valves, and other actuators.
- Communication Speed: For Ethernet communication, it supports data transfer rates of up to 100 Mbps. For other communication protocols like Modbus and Profibus, the communication speed can be configured according to the specific requirements of the network.
