3500/42M

Description

Parameters and specifications:

Model: 3500/42M
Type: 4 channel monitor
Input voltage: 24vdc
Output voltage: 0~10vdc
Purpose: For monitoring and analyzing the vibration of industrial equipment, providing continuous, on-line monitoring function for mechanical protection applications

Size and weight:

Monitor module (motherboard) :
Dimensions (H x W x D) : 241.3mm x 24.4mm x 241.8mm (9.50in x 0.96in x 9.52in)
Weight: 0.91kg (2.0lbs.)
I/O module (without safety gate) :
Dimensions (H x W x D) : 241.3mm x 24.4mm x 99.1mm (9.50in x 0.96in x 3.90in)
Weight: 0.20kg (0.44lbs.)

I/O module (with safety grid) :
Dimensions (H x W x D) : 241.3mm x 24.4mm x 163.1mm (9.50in x 0.96in x 6.42in)
Weight: 0.46kg (1.01lbs.)

Functions:

The 3500/42M vibration monitoring module is used to monitor the vibration level of rotating machinery equipment (such as engines, pumps, compressors, etc.) to assess the operating status of the equipment, to help users find abnormal vibration of the equipment early, and to take corresponding maintenance and maintenance measures to ensure the safe operation of the equipment and extend the service life of the equipment
