1C31204G01

Description

• Power Supply: It operates on 24V DC, with a power consumption of around 8 – 12W, making it energy – efficient for various industrial scenarios.

• Input/Output:

• • Digital Inputs: Equipped with 16 digital inputs, accepting signals from sensors like proximity sensors and limit switches, with an input voltage range of 5 – 24V DC.

• • Digital Outputs: 8 digital outputs, each capable of driving a 1A – current load, suitable for controlling relays, solenoid valves, etc.

• • Analog Inputs: 4 analog inputs can handle signals in the 0 – 10V or 4 – 20mA ranges, with 12 – bit resolution for accurate physical quantity measurement.

• • Analog Outputs: 2 analog outputs for analog control, providing signals in similar ranges.

• Communication Interface: Features an Ethernet interface supporting the TCP/IP protocol, enabling high – speed data transfer within the network for seamless integration into control and monitoring systems. It also supports 10/100 m transfer rates, and can work in both half – duplex and full – duplex modes, with compatibility for straight – through and twisted – wire connections. Additionally, it supports protocols like srtp, egd and channels (product & consumer) modbus tcp.

• Industrial Automation: In manufacturing plants, it controls robotic arms, conveyor belts, etc., and collects sensor data. For example, in a metal – processing factory, it manages the operation of processing equipment and monitors production parameters.

• Building Automation: Manages HVAC systems, lighting, and access control in commercial and residential buildings. It adjusts settings according to environmental conditions and user needs, such as maintaining a comfortable indoor temperature in an office building.

• Power Generation and Distribution: Monitors electrical parameters like voltage, current, and frequency in power plants and substations, and controls generators and distribution equipment to ensure stable power supply.

• Weight: Approximately 0.85 kg, which is manageable for installation and transportation with appropriate equipment.

• Dimensions: With a length of 178 mm, a width of 140 mm, and a height of 73 mm, it can be installed in industrial control cabinets or on DIN rails.

• High – Speed Communication: The Ethernet interface ensures rapid and reliable data exchange, allowing for real – time monitoring and control.

• Flexible Configuration: The combination of digital and analog I/O offers great flexibility to meet diverse industrial requirements.

• Advanced Security: Equipped with four – level password protection, OEM password protection, and block view and edit locking functions, enhancing system security.

• Communication Interface Protection: Its recessed Ethernet interface design protects communication lines from accidental damage.

• Built – in Switches: Built – in switches reduce hardware costs and simplify the network architecture.

• Robust Housing: The durable housing safeguards it from dust, moisture, and minor mechanical impacts, ensuring stable operation in industrial settings.

• Electrical Fault Protection: Built – in over – current, short – circuit, and over – voltage protection functions enhance device reliability and durability.

• Quality Manufacturing: Stringent quality standards during manufacturing guarantee long – term reliable operation.

• Automotive Manufacturing Plant: In a car factory, 1C31204G01 controls the assembly line. It coordinates the movement of robotic arms to accurately install parts, and monitors the speed and operation status of conveyor belts through sensors, improving production efficiency and product quality.

• Commercial Shopping Mall: In a large – scale shopping mall, it manages the HVAC system. By collecting data from temperature and humidity sensors, it adjusts the operation of air – conditioners and ventilation equipment, providing a comfortable shopping environment for customers while saving energy.
