Description
Parameters & Specifications:
Brand: Schneider
Model: 140XCP51000
Operating System: DCS system
Output Frequency: 56/63Hz
Working Voltage: 24Vdc/120Vac
Profibus DP Interface: Supports up to 155M dual optical interfaces, enabling high-speed, long-distance transmission, electrical and ground isolation, and reduced interference
Dimensions & Weight:
Size: 10*16*23mm
Series:
The 140XCP51000 belongs to Schneider’s series of industrial-grade modules designed for automation and control applications.
Features:
Dual Profibus DP Support: Allows for flexible configuration with 1~2 electrical and 1~2 optical interfaces, supporting redundant dual-network fiber ring topology
High-Speed Transmission: Capable of transmitting data at rates up to 155Mb/s over a distance of 20km or more
Industrial-Grade Design: IP30 protection level, wave-textured aluminum reinforced enclosure, 35mm DIN rail mounting, and DC(9-36)V wide power input
Relay Alarm Output: Provides relay output for power failure and fiber link fault alarms, enhancing system reliability
Built-In Protection: Features 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection for the electrical interface
Functions/Role:
The SCHNEIDER 140XCP51000 module is primarily used in industrial automation and control systems. It offers efficient analog input/output capabilities, making it suitable for applications in power plants, steel mills, cement plants, ships, and paper mills
With its support for dual Profibus DP buses and high-speed optical interfaces, the module enables reliable and high-speed data transmission over long distances, which is crucial for large-scale industrial installations
The module’s industrial-grade design and built-in protections ensure its durability and reliability in harsh environments, contributing to the overall stability and efficiency of the control system
