Description
The parameter :
- Output quantity : 16
- Output voltage : 5~30V DC, 30~150V DC, and 20~250V AC
- power consumption : 5.5W+(number of 0.5x power points)
- minimum load : For 5~30V DC, minimum load current is >=50mA; For 20~250V AC, is also >=50mA
- The maximum load current : under certain conditions, , such as 30~50V DC up to 300mA ( resistance) ; up to 2A ( resistively, 60°C) at 250V AC
Specifications :
- Product or component type : relay discrete output module
- The address requirements are : 1 Output word
- insulation performance : The insulation between each channel and bus is 2500V DC for 1 minute, and the insulation between group is 1780Vrms AC for 1 minute.
Dimensions and weight :
- Weight : 0.41kg
Function :
- discrete output : In the industrial automation control system, is used to control a variety of discrete equipment, such as motor, valve, relay and so on
- system integration : As a part of PLC system, works with other modules and equipment to achieve complex automatic control tasks
