Description
Surge current:
<=30A per point within 1 cycle
<=20A per point within 2 cycles
<=10A per point within 3 cycles
Response time:
<=0.5ms in state 1 to state 0
<=0.5ms in the 0 to 1 state
Protection type: Internal through RC filter
Fuse rating: 5A
Size and weight
Size: 132mm105mm52mm
Weight:
In some search results, the weight is labeled as 0.485kg
But in another, the weight is marked as 123kg, which could be an error or a specific configuration of the weight.
Parameters and specifications
Output quantity/Output type/Output voltage/Power consumption:
Output quantity: 16
Output type: insulation
Output voltage: 20~253V AC
Power consumption: 1.85+(1.1Vx total module load current)
Maximum output:
Absolute maximum output: 400 Vrms 1 cycle AC; 300 Vrms is used for 10s communication
Load current:
Maximum load current:
4A rms 24 ~ 115V per output
3A rms 200 ~ 230V per output
4A rms Four consecutive outputs
Open state leakage:
2.5mA rms 230Vrms per output
2mA rms 115Vrms Each output
1mA Valid Value 48Vrms per output
1mA Valid value 24Vrms per output
